Insert into a SharePoint List using ASP.Net

This post describes how to insert into a SharePoint list using ASP.Net. First add a reference to the SharePoint DLL for your specific version. I’m working with SharePoint 2010, and the DLL can be found in the following location:

C:\Program Files\Common Files\Microsoft Shared\Web Server Extensions\14\ISAPI\Microsoft.SharePoint.dll

Ensure in your page that you import the namespace:

using Microsoft.SharePoint;

Now I’ve just dumped some example code below, which inserts into a Text field (obtained from a Textbox), a Multi choice field (obtained from a CheckList box) and a User field (obtained from a SharePoint PeopleEditor control). I’ve also left a few comments in intentionally, as I tried different ways of doing things. I found that if I ran this chunk of code with elevated privileges it inserted the entry into the list but didn’t trigger the associated workflow. I also tried to run it as an impersonated user, but it still didn’t trigger the workflow. So I commented out the RunWithElevated privileges line and it all worked well – the list item inserted and the associated workflow triggered.

You can also see that for the list name, I store this in the Web.Config file since I use the same list throughout the site.

//we can use this to run in the context of a specific user, by passing in
//superToken to SPSite
// var user = SPContext.Current.Web.AllUsers[@"domain\user"];
//var superToken = user.UserToken;
//**IMPORTANT - Cannot run elevated otherwise Workflow wont run!!**
// SPSecurity.RunWithElevatedPrivileges(delegate
using (SPSite oSite = new SPSite(ConfigurationManager.AppSettings["ApplicationPortal"].ToString()))
using (SPWeb oweb = oSite.OpenWeb())
oSite.AllowUnsafeUpdates = true;
oweb.AllowUnsafeUpdates = true;
SPList supportLib = oweb.Lists[ConfigurationManager.AppSettings["UAMRequestList"].ToString()];
SPListItem newItem = supportLib.Items.Add();
//add a string to a Text field
newItem["Title"] = "My Title";
//add to a multi choice field
SPFieldMultiChoiceValue tp = new SPFieldMultiChoiceValue();
//loop through each item in the checkbox list.  If checked, add it
foreach (ListItem cBox in targetplatformCBL.Items)
if (cBox.Selected)
newItem["Target_x0020_Platform"] = tp;
//add to a User field
// SPUser user = oweb.EnsureUser("domain\\user");
//string sRequester = user.ID.ToString() + ";#" + user.LoginName.ToString();
// newItem["Requester"] = sRequester;
PickerEntity entPropMgr = (PickerEntity)requesterPE.ResolvedEntities[0];
SPFieldUserValue Proposalmgrvalue = new SPFieldUserValue(SPContext.Current.Web, Convert.ToInt16(entPropMgr.EntityData[PeopleEditorEntityDataKeys.UserId]), entPropMgr.Description);
newItem["Requester"] = Proposalmgrvalue;
catch (SPException ex)
//handle exception


Using VBScript, CAML queries and SOAP to Read from a Sharepoint List

We use a Sharepoint list to track various information. The toolsets that we create should ideally read from these lists, so that every team member shares the same information and can see real-time data. To do this, we used VBScript (we made a HTA actually…).

It uses a SOAP request to ‘ask’ for information from Sharepoint. Part of this request uses a CAML query to specify exactly what we’re after.

Option Explicit
Dim url, list, viewFields, request, xmlDoc, elements, colItem, objItem, queryNode, clientname, resultsArray, xmlArray(), strItem, spclientname
Set xmlDoc = CreateObject("MSXML2.DOMDocument.6.0")
xmlDoc.async = False
url = "http://xxxx/_vti_bin/Lists.asmx"
'search in client list for 'Multi Client', where LinkTitle equals 'Multi Client', and bring me back the target platform
resultsArray = getResults("331609D1-793D-4075-BC88-570956C6D729","LinkTitle","Multi Client","ows_Target_x0020_Platform")
'do what we want with the clients here
For Each strItem in resultsArray
Wscript.Echo strItem
Function getResults(splist, spwhere, spvalue, spreturnattribute)
request = "<?xml version='1.0' encoding='utf-8'?>" & _
"<soap:Envelope xmlns:xsi='' xmlns:xsd='' xmlns:soap=''>" & _
"  <soap:Body>" & _
"    <GetListItems xmlns=''>" & _
"      <listName>" & splist & "</listName>" + _
"      <query><Query xmlns=''>" & _
"      <Where>" & _
"      <Eq>" & _
"      <FieldRef Name='" & spwhere & "'/>" & _
"      <Value Type='Text'>" & spvalue & "</Value>" & _
"      </Eq>" & _
"      </Where>" & _
"      </Query>" & _
"      </query>" & _
"    </GetListItems>" & _
"  </soap:Body>" & _
'post it up and look at the response
with CreateObject("Microsoft.XMLHTTP")
.open "Get", url, False, null, null
.setRequestHeader "Content-Type", "text/xml; charset=utf-8"
.setRequestHeader "SOAPAction",""
.send request
xmlDoc.setProperty "SelectionLanguage", "XPath"
xmlDoc.async = false
xmlDoc.validateOnParse = false
xmlDoc.resolveExternals = false
xmlDoc.setProperty "SelectionNamespaces", "xmlns:s='uuid:BDC6E3F0-6DA3-11d1-A2A3-00AA00C14882' xmlns:soap='' xmlns:namespace='' xmlns:rs='urn:schemas-microsoft-com:rowset' xmlns:z='#RowsetSchema'"
'dim strQuery : strQuery = "//soap:Envelope/soap:Body/namespace:GetListItemsResponse/namespace:GetListItemsResult/namespace:listitems/rs:data/z:row"
dim strQuery : strQuery = ".//z:row"
Set colItem = xmlDoc.selectNodes(strQuery)
Dim objItemCount : objItemCount = 0
'clear array
ReDim xmlArray(objItemCount)
'wscript.echo "No of Items: " & colItem.Length
For Each objItem in colItem
ReDim Preserve xmlArray(objItemCount)
xmlArray(objItemCount) = objItem.getAttribute(spreturnattribute)
objItemCount = objItemCount + 1
Set colItem = Nothing
'we could use this if we didnt filter it during the request
'Set queryNode = xmlDoc.selectSingleNode(".//z:row[@ows_LinkTitle = '" & clientname & "']")
'wscript.echo queryNode.getAttribute("ows_Target_x0020_Platform")
'Set queryNode = Nothing
Set xmlDoc = Nothing
getResults = xmlArray
end with
End Function


The example above pulls back ALL fields from the list. We may want to refine this to only pull back specific fields by adding the following to our SOAP request:

    " 	   <viewFields><ViewFields><FieldRef Name='COMPANYNAME_x0020_Property' /><FieldRef Name='USERNAME_x0020_Property' /></ViewFields></viewFields>" + _
"    <queryOptions>" + _
" 	       <QueryOptions>" + _
" 	           <IncludeMandatoryColumns>FALSE</IncludeMandatoryColumns>" + _
" 	           <ViewFieldsOnly>TRUE</ViewFieldsOnly>" + _
" 	       </QueryOptions>" + _
" 	   </queryOptions>" + _

The first viewFields tag above should be at the same level as the <query> tag in the example above. In other words, you can paste this code directly above the <query> line in the SOAP request.

Using Powershell, CAML queries and SOAP to Read from a Sharepoint List

Similarly to my post here this post describes how we can use Powershell to extract information from a Sharepoint list.

$list = $null
$service = $null
# The uri refers to the path of the service description, e.g. the .asmx page
$uri = "http://xxx/_vti_bin/Lists.asmx"
# Create the service
$service = New-WebServiceProxy -uri $uri -Namespace SpWs -UseDefaultCredential
$service.url = $uri
# The name of the list
$listName = "331609D1-793D-4075-BC88-570956C6D729"
$xmlDoc = new-object System.Xml.XmlDocument
$queryOptions = $xmlDoc.CreateElement("QueryOptions")
$queryOptionsString = "<IncludeMandatoryColumns>FALSE</IncludeMandatoryColumns><DateInUtc>TRUE</DateInUtc><ViewAttributes Scope='RecursiveAll' />"
$query = $xmlDoc.CreateElement("Query")
$queryString = "<OrderBy><FieldRef Name='Title' Ascending='TRUE' /></OrderBy>"
$rowLimit = "999"
$list = $service.GetListItems($listName, "", $query, $viewFields, $rowLimit, $queryOptions, "")
write-host ($_.Exception).Message

Once I’d received the list of values back as a System.Xml.XmlNode object, I added them to a Combobox like this:

foreach ($node in $ {
$customerBox.items.add($node.GetAttribute("ows_Title")) | Out-Null

Incidentally, I needed to retrieve some more values from my Sharepoint list for use later on. Rather than doing another Web service request, I decided to store the values I needed during the first request so I could use them later. I updated the for loop above like so:

foreach ($node in $ {
"uname" = ($node.GetAttribute("ows_FTP_x0020_Username"))
"pword"   = ($node.GetAttribute("ows_FTP_x0020_Password"))
$customerBox.items.add($node.GetAttribute("ows_Title")) | Out-Null

You can see that we’ve used a hash table to store the results. Not only is it a hash table, but it’s a hash table inside another hash table!!

A hash table is similar to the VBScript Dictionary object in that it stores key-value pairs. In our example above, the key is:


and the value is another hash table of:

“uname” = ($node.GetAttribute(“ows_FTP_x0020_Username”))
“pword” = ($node.GetAttribute(“ows_FTP_x0020_Password”))

and how do we retrieve these values? Easy…

$ftpuname = $FTPhash.Get_Item($customerBox.SelectedItem).uname
$ftppassword = $FTPhash.Get_Item($customerBox.SelectedItem).pword



I’ve just used this code in another environment and for a different client. I was getting:

Exception calling “GetListItems” with “7” argument(s)

And the detailed exception didn’t tell me much. It turns out it was to do with the service URL.

If i initially created the service with a URL such as and immediately afterwards I echoed out:


It would return the URL as being:!! (Notice the difference!) This is actually the site URL! Hence I now explicitly set the URL of the web service proxy after we create it using:

$service.url = $uri
